FANUC A06B-0202-B301 α1/5000i Brake Servo Motor with α1000iI Pulsecoder

The FANUC A06B-0202-B301 α1/5000i AC servo motor is a brake-equipped 0.5kW model designed for CNC applications requiring axis holding and reliable feedback. This version uses a taper shaft, 24VDC brake, and α1000iI pulsecoder. It is suitable for compact machine tool axes, positioning mechanisms, and feed systems where a brake is required to maintain position after stop. The motor should be used with compatible FANUC αi servo amplifier modules and verified against the original machine parameters. It is a useful replacement option for repair companies and end users maintaining FANUC CNC equipment.

FAQ

What is FANUC A06B-0202-B301?

It is a 0.5kW FANUC α1/5000i servo motor with taper shaft, 24VDC brake, and α1000iI pulsecoder.

What is the difference between B301 and B001?

Both use taper shaft and α1000iI pulsecoder. B301 has a 24VDC brake, while B001 has no brake.

Is A06B-0202-B301 suitable for vertical axes?

It may be suitable for holding or vertical applications if the machine wiring and brake control support this brake configuration.

Can A06B-0202-B301 replace B300?

The shaft and brake are the same, but the pulsecoder type is different. CNC parameters and feedback compatibility must be checked.

What should be included in an inquiry?

Please include the full motor suffix, nameplate photo, amplifier part number, machine model, and brake requirement.
